Switch Huawei CloudEngine S5735R-L48LP4X-A-V2
CloudEngine S5735R-L48P4X-A-V2 48 × 10/100/1000BASE-T (PoE+), 4 × 10GE SFP+ uplink ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735R-L48LP4X-A-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735R-L48P4X-A-V2 |
| Product Series | CloudEngine S5735R-L-V2 |
| Fixed Ports | 48 × 10/100/1000BASE-T (PoE+), 4 × 10GE SFP+ uplink ports |
| Switching Capacity | 176 Gbps / 520 Gbps (system switch capacity) |
| Forwarding Performance | 132 Mpps |
| PoE Support | Yes — PoE+ |
| Maximum PoE Power | 1000 W AC power module slot; 846 W PoE power (at 220 V) |
| Number of Ports with Full PoE+ | Up to 28 ports at 30 W (802.3at) when fully loaded |
| Typical Power Consumption | 54.78 W |
| Maximum Power Consumption | Without PoE: 76.66 W; Full PoE load: ~993.74 W |
| Dimensions (H × W × D) | 43.6 mm × 442.0 mm × 420.0 mm |
| Maximum Depth including protrusions | 446.0 mm |
| Chassis Height | 1 U |
| Weight (without packaging) | 6.10 kg |
| Weight (with packaging) | 8.90 kg |
| Airflow & Cooling | Two built-in fans; forced air cooling; airflow intake from front, left, right; exhaust rear |
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| Power Supply Slot | One power module slot (AC, supports up to 1000 W PoE module) |
| condition | new |
|---|
