Switch Huawei CloudEngine S5735R-L48P4X-A-V2
CloudEngine S5735R-L48LP4X-A-V2 48 × 10/100/1000BASE-T (PoE+), 4 × 10GE SFP+ uplink ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735R-L48P4X-A-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735R-L48LP4X-A-V2 |
| Product Series | CloudEngine S5700 / S5735R / S5735-L-V2 |
| Fixed Ports | 48 × 10/100/1000BASE-T (PoE+), 4 × 10GE SFP+ uplink ports |
| Switching Capacity | 176 Gbps |
| Forwarding Performance | 132 million packets per second (132 Mpps) |
| Typical Power Consumption | 48.64 W |
| Maximum Power Consumption (no PoE) | 63.70 W |
| Maximum Power Consumption (full PoE load) | 462.80 W (with PoE: 380 W) |
| Static Power Consumption | 34.04 W |
| Dimensions without packaging (H × W × D) | 43.6 mm × 442.0 mm × 220.0 mm |
| Maximum dimensions (depth incl. protrusions) | 43.6 mm × 442.0 mm × 227.0 mm |
| Dimensions with packaging | 90.0 mm × 550.0 mm × 360.0 mm |
| Chassis Height | 1 U |
| Weight without packaging | 3.24 kg |
| Weight with packaging | 4.29 kg |
| Fan Modules | 2 built-in fans for forced air cooling |
| Operating Temperature (Long-term) | -5°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity (Long-term, non-condensing) | 5% to 95% |
| Ingress Protection Level | IP20 |
| Power Supply Mode / Input Voltage | Built-in AC; 100-240 V AC, 50/60 Hz; also 240 V DC input possible |
| PoE Support | Yes — PoE+ |
| condition | new |
|---|
