Switch Huawei CloudEngine S5735R-L8T4X-QA-V2
CloudEngine S5735R-L8T4X-QA-V2 8 × 10/100/1000 Base-T ports 4 × 10 GE SFP+ ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735R-L8T4X-QA-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735R-L8T4X-QA-V2 |
| Fixed Ports | 8 × 10/100/1000 Base-T ports4 × 10 GE SFP+ ports |
| Forwarding Performance | 72 Mpps |
| Switching Capacity | 96 Gbps (device) / 520 Gbps (system-wide) |
| Memory | 2 GB RAM, 1 GB Flash |
| Form Factor | 1U rack-mount chassis |
| Power Supply System | Built-in AC power module (no redundancy slot) |
| Cooling System | Fanless (natural heat dissipation) |
| Physical Ports & Buttons | Console (RJ-45), MODE button, PnP button, ground screw, AC socket |
| Rated Input Voltage | 100–240 V AC, 50/60 Hz |
| Maximum Input Current | ≤ 0.8 A |
| Power Supply Surge Protection | ±6 kV differential & common mode |
| Ingress Protection | IP20-rated enclosure |
| Operating Conditions | –40 °C to +70 °C (storage); 5%–95% RH non-condensing; altitude 0–5000 m |
| PoE Support | Not supported |
| Layer 2/3 Features | Static routing, RIP/RIPng, OSPF/OSPFv3, VLANs up to 4094, MAC authentication, security controls (exact suite varies by software version) |
| condition | new |
|---|
