Switch Huawei CloudEngine S5735R-S24P4X-V2
CloudEngine S5735R-S24P4X-V2 24 × 10/100/1000Base-T ports 4 × 10GE SFP+ uplink ports 2 × 12GE stack ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735R-S24P4X-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735R-S24P4X-V2 |
| Fixed Ports | 24 × 10/100/1000Base-T ports 4 × 10GE SFP+ uplink ports 2 × 12GE stack ports |
| Form Factor | 1U rack-mounted chassis |
| Switching Capacity | 128 Gbps / 520 Gbps |
| Forwarding Performance | 96 Mpps |
| Power Supply | Built-in dual AC power modules, 1+1 redundancy |
| Cooling System | Two built-in fans; fans idle at normal temperature and activate automatically at high temperature; airflow intake from front/sides, exhaust rear |
| Typical Power Consumption | 39.43 W |
| Maximum Power Consumption | 45.80 W (with two 600 W AC power modules) 55.70 W (with two 1000 W AC power modules) |
| Heat Dissipation | 134.54 BTU/h |
| Dimensions (H × W × D) | 43.6 × 442.0 × 420.0 mm; maximum depth with protrusions: 446.0 mm |
| Weight (without packaging) | 4.80 kg |
| Weight (with packaging) | 7.74 kg |
| Reliability (MTBF) | ~124 years; availability >99.999% |
| Noise Level | Silent at normal operation (fans idle), increases only at high temperature |
| Layer 3 Features | Static routing, RIP/RIPng, OSPF/OSPFv3, IS-IS/IS-ISv6, BGP/BGP4+, VRRP/VRRP6, ECMP, policy-based routing |
| Multicast Support | IGMP snooping, PIM-SM, PIM-DM, PIM-SSM |
| Security Features | MAC authentication, 802.1X, DHCP snooping, ARP protection, IP Source Guard, DoS defense |
| Reliability Features | STP/RSTP/MSTP, ERPS (<50 ms switching), Smart Link |
| Stacking (iStack) | Supported; multiple units can operate as one logical switch |
| O&M & Management | Zero-touch deployment, USB configuration, SNMP, CLI, Web, SSH, telemetry |
| IPv6 Capabilities | IPv4/IPv6 dual stack, RIPng, OSPFv3, IS-ISv6, IPv6 transition mechanisms |
| PoE | Not supported |
| Use Cases | Suitable for campus access/aggregation layers and data center access layer |
| condition | new |
|---|
