Switch Huawei CloudEngine S5751-L8P2PN2X-RUA
CloudEngine S5751-L8P2PN2X-RUA 8 × 10/100/1000BASE-T ports (with PoE+) (of which 6 are PoE+ typical, 2 are 2.5G capable)
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications of the switch Huawei CloudEngine S5751-L8P2PN2X-RUA:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5751-L8P2PN2X-RUA |
| Ports – Downlink | 8 × 10/100/1000BASE-T ports (with PoE+) (of which 6 are PoE+ typical, 2 are 2.5G capable) |
| Ports – Uplink | 2 × 10GE SFP+ ports; hybrid optical-electrical capable (multi-rate) |
| Switching Capacity | 98 Gbps |
| Forwarding Performance | ~ 49.5 million packets per second (Mpps) |
| PoE Support | Yes — PoE+, possibly PoE++ in parts (depending on load) |
| Maximum PoE Power Budget | 128 W |
| Power Supply Type | AC power adapter |
| Typical Power Consumption | ~ 16.74 W (when under normal load) |
| Maximum Power Consumption (with full PoE load) | ~ 162.05 W |
| Static Power Consumption | ~ 7-14 W depending on configuration |
| Dimensions (without packaging H × W × D) | 43.6 mm × 195 mm × 160 mm |
| Weight (without packaging) | ~ 1.2 kg |
| Weight (with packaging) | ~ 2.38 kg |
| Ingress Protection Level | IP20 |
| Heat Dissipation / Cooling | Fanless; natural air cooling |
| Operating Temperature | –5 °C to +45 °C |
| Storage Temperature | –40 °C to +70 °C |
| Relative Humidity (Operating, non-condensing) | 5% to 95% |
| Altitude (Operating) | 0 to 5000 m (approx.) |
| Surge Protection (Power Port) | Differential mode ±4 kV; Common mode ±4 kV |
| MTBF (Mean Time Between Failures) | ~ 83-84 years |
| condition | new |
|---|
