Switch Huawei CloudEngine S5751-L8P2X-RUA
CloudEngine S5751-L8P2X-RUA 8 × 10/100/1000BASE-T ports (PoE+)
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications of the switch Huawei CloudEngine S5751-L8P2X-RUA:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5751-L8P2X-RUA |
| Series / Family | CloudEngine S5751-L Remote Unit Switch |
| Downlink Ports | 8 × 10/100/1000BASE-T ports (PoE+) |
| Uplink Ports | 2 × 100M/1G/2.5GE SFP+ ports |
| Switching Capacity | 98 Gbps |
| Forwarding Performance | 42 million packets per second (42 Mpps) |
| PoE Support | Yes — PoE+ |
| Power Supply Type | AC power adapter |
| Static Power Consumption | ~ 7.15 W |
| Typical Power Consumption | ~ 13.14 W |
| Maximum Power Consumption (full PoE load) | ~ 128 W (when all PoE ports loaded) |
| Dimensions (without packaging, H x W x D) | 43.6 mm × 195 mm × 160 mm |
| Maximum Depth including protruding parts | 166.2 mm |
| Weight (without packaging) | ~ 1.16 kg |
| Weight (with packaging) | ~ 2.11 kg |
| Ingress Protection Level | IP20 |
| Cooling / Fan | Fanless; natural heat dissipation |
| Operating Temperature (Long-term) | -5 °C to +45 °C |
| Storage Temperature | -40 °C to +70 °C |
| Relative Humidity (Operating, non-condensing) | 5% to 95% |
| Altitude (Operating) | 0 to 5000 m |
| Surge Protection (Power Input) | Differential mode ±4 kV; common mode ±4 kV |
| MTBF (Mean Time Between Failures) | ~ 84.12 years |
| condition | new |
|---|
