Switch Huawei CloudEngine S5751-L8T2HJ-RUA
CloudEngine S5751-L8T2HJ-RUA 8 × 10/100/1000BASE-T ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications of the switch Huawei CloudEngine S5751-L8T2HJ-RUA:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5751-L8T2HJ-RUA |
| Product Series / Family | CloudEngine S5751-L Remote Unit Switches |
| Downlink Ports | 8 × 10/100/1000BASE-T ports |
| Uplink Ports | 2 × hybrid optical-electrical SFP ports, supporting 100M / 1G / 2.5G |
| Switching Capacity | 98 Gbps |
| Forwarding Performance | 19.5 million packets per second (19.5 Mpps) |
| PoE Support | Not supported (no PoE in this model) |
| Power Supply Type | Hybrid power cable, Phoenix terminal, or AC adapter |
| Typical Power Consumption | ~ 5.06 W |
| Static Power Consumption | (Device idle) lower; exact static value ~ 4-5 W |
| Dimensions (Height × Width × Depth) | 35 mm × 195 mm × 130 mm |
| Weight (Chassis without packaging) | ~ 0.6 kg |
| Installation Methods | Desk or wall mounting |
| Operating Temperature Range | −5 °C to +45 °C |
| Storage Temperature Range | −40 °C to +70 °C |
| Relative Humidity (Operating, non-condensing) | 5% to 95% |
| Ingress Protection Level | IP20 |
| Heat Dissipation / Cooling | Fanless; natural heat dissipation |
| Surge Protection (Power Input port) | ± 4 kV differential mode; ± 4 kV common mode |
| condition | new |
|---|
