Huawei S5700 – a series of high-performance, innovative switches that consist of a large number of devices and with a different number of 1G ports. Switches are equipped with interfaces uplink 10G and huge software functionality (software).
switches Huawei S5700 Designed for use in locations that require excellent, high throughput, low latency and fault tolerance.
Depending on the functionality of the software, the switches of the series Huawei S5700 divided into four types.
Category CloudEngine S5735-L assembled simplified switches at gigabit speeds, which may include from 12 up to 48 flexible downlinks GE ports at all speeds and four fixed uplinks port 10 GE.
Switches are based on a high-performance platform of a unique design and a universal routing platform Huawei — Versatile Routing Platform (VRP).
This switch series features: improved functionality 3-level, simplified operation and maintenance tools and flexible ways to organize the Internet.
Specifications switch Huawei S5735-L8P4X-IA1:
|
Parameters
|
CloudEngine S5735-L8T4X-IA1
|
CloudEngine S5735-L8P4X-IA1
|
CloudEngine S5735-L24T4X-IA1
|
|
Forwarding Performance
|
72 Mpps
|
72 Mpps
|
96 Mpps
|
|
Switching Capacity
|
96/336 Gbit/s
|
96/336 Gbit/s
|
128/336 Gbit/s
|
|
Ports
|
8 x 10/100/1000Base-T ports and 4 x 10 GE SFP+ ports
|
8 x 10/100/1000Base-T ports and 4 x 10 GE SFP+ ports
|
24 x 10/100/1000Base-T ports and 4 x 10 GE SFP+ ports
|
|
Operating Temperature
|
–40°C to +70°C
|
–40°C to +70°C
|
–40°C to +70°C
|
|
Surge Protection
|
Built-in surge protection to handle harsh outdoor environments
|
Built-in surge protection to handle harsh outdoor environments
|
Built-in surge protection to handle harsh outdoor environments
|
|
Relative Humidity
|
5–95% (non-condensing)
|
5–95% (non-condensing)
|
5–95% (non-condensing)
|
|
Heat Dissipation
|
Heat dissipation with fans and intelligent fan speed adjustment
|
Heat dissipation with fans and intelligent fan speed adjustment
|
Heat dissipation with fans and intelligent fan speed adjustment
|
