Switch NVIDIA Spectrum SN3700
32 QSFP56 200GbE Frequency: 50–60Hz Input range: 100–264Vac AC input current: 2.9–4.5A
Network switches NVIDIA Spectrum™ SN3000 – These are innovative devices designed to work in modern data processing centers. Are equipped ASIC second generation, they provide high bandwidth, minimal delay and a wide range of port velocities - from 1 to 1 to 200 GbIT/with. This allows you to efficiently connect servers in scaled infrastructures Leaf-Spine, Superspin, as well as in cloud and hyperconvertent environments.
Switches SN3000 Supports flexible configurations of uplink ports, which allows for optimal selection of the blocking factor depending on the needs of the network. Thanks to support SDN and extended set Layer 2/3 functions, series is suitable for tasks of high -performance computing, data analytics and cloud -building.
Open Nvidia Open Ethernet ™ architecture removes restrictions on proprietary solutions, allowing you to use various operating systems and create adaptive, independent network environments. This simplifies the deployment, improves controllability and increases the network efficiency by reducing operating costs.
SN3000 – It is a reliable solution for a date centers of any scale where speed, scalability and flexibility are important.
Specifications of the switch NVIDIA Spectrum SN4600C:
| Feature | Specification |
|---|---|
| Model | NVIDIA Spectrum SN4600C |
| Switch Type | Data Center Ethernet Switch |
| Form Factor | 2U Rackmount |
| Ports | 64 x 100GbE QSFP28 |
| Supported Speeds | 1/10/25/40/50/100GbE per port |
| Throughput | 6.4 Tbps |
| Forwarding Rate | 8.4 Bpps (Billion Packets Per Second) |
| Packet Buffer | 64 MB |
| Processor | Intel x86 2.2 GHz Quad-Core |
| Memory | 8 GB RAM, 30 GB SSD |
| Power Consumption | Typical: 466W with passive cables (ATIS) |
| Power Supply Units | 2 internal, hot-swappable, 1+1 redundancy |
| Cooling | Dual hot-swappable fans |
| Dimensions (W x D x H) | 428 mm x 566.4 mm x 88 mm |
| Weight | 14.64 kg |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | Operating: 10%-85% (non-condensing), Storage: 10%-90% (non-condensing) |
| Altitude | Up to 3050 m |
| Certifications & Standards | CB, cTUVus, CE, CU, S_Mark, FCC, VCCI, ICES, RCM, BSMI, KCC, CCC; RoHS Compliant |
| condition | new |
|---|
