Transceiver Nvidia 980-9I16Y-00W000
The NVIDIA 980-9I16Y-00W000 is a QSFP-DD (Quad Small Form-factor Pluggable Double Density) transceiver module that supports 8x50G PAM4 lanes, providing a total aggregate data rate of 400 Gbps. It utilizes a 1310 nm wavelength for transmission over SMF, with a reach of up to 500 meters when using an MPO-12 connector. The module features Digital Optical Monitoring (DOM) for real-time diagnostics and operates within a commercial temperature range
Modulation -based equipment 100G-PAM4 Provides transmission of data at speed to 400 GbIT/s and used in InfiniBand networks and Ethernet. Technology PAM4 lets double the data density compared to NRZ, which is critical for modern data centers, high-performance computing, and cloud infrastructures.
The ruler includes transversal and cable assembly of formats QSFP112, OSFP and Twin-port OSFP. Supports active (AOC, ACC) and passive (DAC) cables as well as multimode (MMF) and one -mode (SMF) Optical modules. All devices are certified and meet the standards IEEE 802.3bs and InfiniBand HDR.
Implemented various connection schemes:
- 800G-to-800G - Direct connection of switches;
- 800G-to-2x400G - Connecting modules DPU ConnectX-7 and BlueField-3;
- 800G-to-4x200G - Multiple distribution of traffic.
Modules support digital monitoring DDM: temperature control, voltage, radiation power and reception, laser output current. This provides stability during operation and accelerates diagnostics. Also supported FEC-coding that reduces the possibility of loss and errors in high -frequency transmission conditions.
form factor OSFP designed for effective heat dissipation, which allows the use of DSP high power and achieve steady work at distances up to 2 km (SMF). QSFP112 offers compactness and backward compatibility with previous generations, including channels up to 100 m for OM4.
The operating temperature range is from 0 to +70°C. All devices meet the requirements MSA, which ensures cross-compatibility in network solutions from different manufacturers. Equipment is designed to build scaled, rejection and energy -efficient new generation networks where critical speed, density and reliability of data transmission.
The technical characteristics of an optical module Nvidia 980-9I16Y-00W000:
| Parameter | Specification |
|---|---|
| Model | NVIDIA 980-9I16Y-00W000 |
| Form Factor | QSFP-DD |
| Data Rate | 400 Gbps (8x50G PAM4) |
| Wavelength | 1310 nm |
| Fiber Type | Single-Mode Fiber (SMF) |
| Maximum Reach | Up to 500 meters |
| Connector | MPO-12 APC |
| Power Consumption | <10 W |
| Operating Temperature | 0°C to 70°C |
| Digital Diagnostics | Yes (DOM supported) |
| Compliance | IEEE 400GBASE-DR4, RoHS-6 |
| Applications | Data centers, high-speed networking |
| condition | new |
|---|
