Transceiver Nvidia 980-9I17Q-00CM00
The NVIDIA 980-9I17Q-00CM00 is a 100GbE optical transceiver module featuring a QSFP28 form factor and designed for single-mode fiber (SMF) applications. It supports 100GBASE-CWDM4 with a transmission distance of up to 2 km using LC duplex connectors and operates at four wavelengths: 1295 nm, 1300 nm, 1304 nm, and 1309 nm. The module consumes a typical power of 3.5 W and operates within a voltage range of 3.3 V. It supports digital diagnostics monitoring (DDM) via I2C, offers hot-plug and plug-and-play functionality, and is compliant with IEEE 802.3ba 100GBASE-CWDM4 and IEEE 802.3bm CAUI-4 standards.
Modulation -based equipment 100G-PAM4 Provides transmission of data at speed to 400 GbIT/s and used in InfiniBand networks and Ethernet. Technology PAM4 lets double the data density compared to NRZ, which is critical for modern data centers, high-performance computing, and cloud infrastructures.
The ruler includes transversal and cable assembly of formats QSFP112, OSFP and Twin-port OSFP. Supports active (AOC, ACC) and passive (DAC) cables as well as multimode (MMF) and one -mode (SMF) Optical modules. All devices are certified and meet the standards IEEE 802.3bs and InfiniBand HDR.
Implemented various connection schemes:
- 800G-to-800G - Direct connection of switches;
- 800G-to-2x400G - Connecting modules DPU ConnectX-7 and BlueField-3;
- 800G-to-4x200G - Multiple distribution of traffic.
Modules support digital monitoring DDM: temperature control, voltage, radiation power and reception, laser output current. This provides stability during operation and accelerates diagnostics. Also supported FEC-coding that reduces the possibility of loss and errors in high -frequency transmission conditions.
form factor OSFP designed for effective heat dissipation, which allows the use of DSP high power and achieve steady work at distances up to 2 km (SMF). QSFP112 offers compactness and backward compatibility with previous generations, including channels up to 100 m for OM4.
The operating temperature range is from 0 to +70°C. All devices meet the requirements MSA, which ensures cross-compatibility in network solutions from different manufacturers. Equipment is designed to build scaled, rejection and energy -efficient new generation networks where critical speed, density and reliability of data transmission.
The technical characteristics of an optical module Nvidia 980-9I17Q-00CM00:
| Feature | Specification |
|---|---|
| Model | NVIDIA 980-9I17Q-00CM00 |
| Form Factor | QSFP28 (Quad Small Form-factor Pluggable 28) |
| Data Rate | 100 Gbps (100,000 Mbit/s) |
| Interface | 100GBASE-CWDM4 (Coarse Wavelength Division Multiplexing 4) |
| Fiber Type | Single-mode fiber (SMF) |
| Connector Type | LC Duplex (UPC, non-angled) |
| Wavelengths | 1295 nm, 1300 nm, 1304 nm, 1309 nm |
| Maximum Reach | Up to 2 km (2,000 meters) |
| Voltage | 3.3 V (nominal) |
| Power Consumption | 3.5 W (typical) |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 15% to 85% relative humidity (non-condensing) |
| Compliance Standards | QSFP28 MSA, IEEE 802.3ba 100GBASE-CWDM4, IEEE 802.3bm CAUI-4 |
| Digital Diagnostics (DDM) | Supported via I2C interface |
| Hot-Plug Support | Yes |
| Plug-and-Play | Yes |
| Certifications | RoHS, CE, FCC, REACH, EMC |
| condition | new |
|---|
