Transceiver Nvidia 980-9I595-00AM00
The NVIDIA 980-9I595-00AM00 is a hot-pluggable SFP28 transceiver module designed for short-range data communication and interconnect applications. It supports both 10G and 25G Ethernet over multimode fiber (MMF) using an 850 nm wavelength. With an LC duplex connector, this module delivers reliable transmission distances of up to 100 meters over OM4 fiber (70 meters over OM3), making it ideal for high-density networking environments such as data centers and enterprise networks. The transceiver complies with IEEE 802.3by (25GBASE-SR), IEEE 802.3ae (10GBASE-SR), and SFF-8472 with Digital Optical Monitoring (DOM) support.
Modulation -based equipment 100G-PAM4 Provides transmission of data at speed to 400 GbIT/s and used in InfiniBand networks and Ethernet. Technology PAM4 lets double the data density compared to NRZ, which is critical for modern data centers, high-performance computing, and cloud infrastructures.
The ruler includes transversal and cable assembly of formats QSFP112, OSFP and Twin-port OSFP. Supports active (AOC, ACC) and passive (DAC) cables as well as multimode (MMF) and one -mode (SMF) Optical modules. All devices are certified and meet the standards IEEE 802.3bs and InfiniBand HDR.
Implemented various connection schemes:
- 800G-to-800G - Direct connection of switches;
- 800G-to-2x400G - Connecting modules DPU ConnectX-7 and BlueField-3;
- 800G-to-4x200G - Multiple distribution of traffic.
Modules support digital monitoring DDM: temperature control, voltage, radiation power and reception, laser output current. This provides stability during operation and accelerates diagnostics. Also supported FEC-coding that reduces the possibility of loss and errors in high -frequency transmission conditions.
form factor OSFP designed for effective heat dissipation, which allows the use of DSP high power and achieve steady work at distances up to 2 km (SMF). QSFP112 offers compactness and backward compatibility with previous generations, including channels up to 100 m for OM4.
The operating temperature range is from 0 to +70°C. All devices meet the requirements MSA, which ensures cross-compatibility in network solutions from different manufacturers. Equipment is designed to build scaled, rejection and energy -efficient new generation networks where critical speed, density and reliability of data transmission.
The technical characteristics of an optical module Nvidia 980-9I595-00AM00:
| Parameter | Specification |
|---|---|
| Model | NVIDIA 980-9I595-00AM00 |
| Form Factor | SFP28 |
| Data Rate | 10G/25G NRZ |
| Connector | LC Duplex |
| Wavelength | 850 nm |
| Fiber Type | Multimode Fiber (MMF) |
| Reach | Up to 100 m (OM4), 70 m (OM3) |
| Modulation | NRZ |
| Digital Diagnostics | Yes (DOM supported) |
| Hot-Pluggable | Yes |
| Operating Temperature | 0°C to 70°C |
| Standards Compliance | IEEE 802.3by, IEEE 802.3ae, SFF-8472 |
| Applications | 25GBASE-SR, 10GBASE-SR |
| Power Consumption | < 1.0 W |
| Compatibility | Mellanox/NVIDIA switches, network adapters, servers |
| condition | new |
|---|
