Transceiver Nvidia 980-9I71G-00J000
The NVIDIA 980-9I71G-00J000 adapter facilitates the connection of SFP+ modules or cables to QSFP+ ports. This allows a single-lane SFP+ transceiver or cable to connect to a quad-lane QSFP+ port, effectively converting the port to support 10GbE speeds. This solution is particularly useful in data centers and enterprise networks where flexibility and cost-effective upgrades are essential.
Modulation -based equipment 100G-PAM4 Provides transmission of data at speed to 400 GbIT/s and used in InfiniBand networks and Ethernet. Technology PAM4 lets double the data density compared to NRZ, which is critical for modern data centers, high-performance computing, and cloud infrastructures.
The ruler includes transversal and cable assembly of formats QSFP112, OSFP and Twin-port OSFP. Supports active (AOC, ACC) and passive (DAC) cables as well as multimode (MMF) and one -mode (SMF) Optical modules. All devices are certified and meet the standards IEEE 802.3bs and InfiniBand HDR.
Implemented various connection schemes:
- 800G-to-800G - Direct connection of switches;
- 800G-to-2x400G - Connecting modules DPU ConnectX-7 and BlueField-3;
- 800G-to-4x200G - Multiple distribution of traffic.
Modules support digital monitoring DDM: temperature control, voltage, radiation power and reception, laser output current. This provides stability during operation and accelerates diagnostics. Also supported FEC-coding that reduces the possibility of loss and errors in high -frequency transmission conditions.
form factor OSFP designed for effective heat dissipation, which allows the use of DSP high power and achieve steady work at distances up to 2 km (SMF). QSFP112 offers compactness and backward compatibility with previous generations, including channels up to 100 m for OM4.
The operating temperature range is from 0 to +70°C. All devices meet the requirements MSA, which ensures cross-compatibility in network solutions from different manufacturers. Equipment is designed to build scaled, rejection and energy -efficient new generation networks where critical speed, density and reliability of data transmission.
The technical characteristics of an optical module Nvidia 980-9I71G-00J000:
| Parameter | Specification |
|---|---|
| Model | NVIDIA 980-9I71G-00J000 |
| Alternate Part Number | MAM1Q00A-QSA |
| Form Factor | QSFP+ to SFP+ Adapter |
| Data Rate Support | Up to 10 Gbps (SFP+) |
| Connector Interface | QSFP+ (Host Side) to SFP+ (Client Side) |
| Compatibility | Compatible with NVIDIA Mellanox QSFP+ ports |
| Applications | Enables 10GbE connectivity on 40GbE QSFP+ ports |
| Operating Temperature | 0°C to 70°C |
| Hot-Pluggable | Yes |
| Compliance | IEEE 802.3ae, SFF-8431, SFF-8432 |
| condition | new |
|---|
